Computer Connectivity
USB
Form Factor
Desktop
Simultaneous I/O
1 x 2
Number of Preamps
1
Phantom Power
Yes
Bit Depth
24-bit
Sample Rates
44.1 kHz
48 kHz
88.2 kHz
96 kHz
Analog Inputs
1 x  Neutrik XLR-1/4” combo
Analog Outputs
2 x 1/4” (impedance balanced)
1 x 1/4” (headphones)
Direct Monitor
Yes
USB
1 x USB Type C
Bus Powered
Yes
OS Requirements
Mac OS 10.10 or later
Windows 7 or later
Power
USB bus-powered
Depth
100mm total (with knobs)
chassis: 88mm
Width
124mm
Height
38mm
Weight
1lb 3.7oz
560g

Advanced Specifications

INPUT
XLR/MIC INPUT
Dynamic Range
104dBA
Equivalent Input Noise @ Maximum Gain (Source Impedance 150 ohms, 20Hz-20kHz, A-weighted)
–128dBA
Frequency Response (Measured after ADC)
20Hz – 20kHz better than ±1dB
Gain Range
0dB – >45dB
Input Impedance
1.3k Ohms
INSTRUMENT INPUT
Dynamic Range
99dBA
Frequency Response (Measured after ADC)
20Hz – 20kHz better than ±1dB
Gain Range
0dB – >45dB
Input Impedance
900k Ohms
OUTPUTS
MONITOR OUTPUTS
Maximum Output Level
-6dBu
Frequency Response
20Hz – 20kHz better than ±1dB
HEADPHONE
Max output power at 1% THD
32Ohms – >210mW
300Ohms – >390mW
SKU AI-1
Brand Rode
Shipping Weight 2.0000kg
Shipping Width 0.150m
Shipping Height 0.100m
Shipping Length 0.100m
Shipping Cubic 0.001500000m3
