Nominal Input Level
-20 dBu
Input Impedance
1 M ohm
Nominal Output Level
-20 dBu
Output Impedance
1 k ohm
Recommended Load Impedance
10 k ohms or greater
Bypass
Buffered bypass
Controls
MODE selector switch
DECAY knob
THRESHOLD knob
Pedal switch
Indicator
CHECK indicator (Serves also as battery check indicator)
REDUCTION indicator
Connectors
INPUT jack: 1/4-inch phone type
OUTPUT jack: 1/4-inch phone type
SEND jack: 1/4-inch phone type
RETURN jack: 1/4-inch phone type
DC IN jack
9V DC OUT jack
Power Supply
Carbon-zinc battery (9 V, 6F22) or Alkaline battery (9 V, 6LR61)
AC adaptor (PSA series: sold separately)
Current Draw
25 mA
Expected battery life under continuous use
Carbon: Approx. 11 hours
Alkaline: Approx. 24.5 hours
*These figures will vary depending on the actual conditions of use.
Accessories
Owner's manual
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Carbon-zinc battery (9 V, 6F22)
Options (sold separately)
AC adaptor: PSA series
Parallel DC Cord: PCS-20A
Size and Weight
Width
73 mm
2-7/8 inches
Depth
129 mm
5-1/8 inches
Height
59 mm
2-3/8 inches
Weight (including battery)
415 g
15 oz
* 0 dBu = 0.775 Vrms
SKU NS2
Brand BOSS
Shipping Weight 0.4000kg
Shipping Width 0.129m
Shipping Height 0.059m
Shipping Length 0.073m
Shipping Cubic 0.000555603m3
